Crane Spotlight
Model Ranges
As the three manufacturers offering truck cranes in North America, Grove, Link- Belt, and Tadano provide a range of options, including:
Grove
• TMS875-2— 75 tons, main boom length 40- 128 feet, maximum tip height 194.3 feet
• TMS800-2— 80 tons, main boom length 40- 128 feet, maximum tip height 194.3 feet
• TMS9000-2— 115 tons, main boom length 36- 169 feet, maximum tip height 263.4 feet
• TTS9000-2— 115 tons, main boom length 36- 169 feet, maximum tip height 263.4 feet
Link-Belt
• 40 | HT— 40 tons, standard boom 36.8 – 115 feet, maximum tip height 171 feet
• 65 | HT— 65 tons, standard boom 36.8 – 115 feet, maximum tip height 171 feet
• HTC-8675 SII— 75 tons, standard boom 41 – 127 feet, maximum tip height 230 feet
• HTC-86100— 100 tons, standard boom 38 – 140 feet, maximum tip height 237 feet
• HTC-86110— 110 tons, standard boom 38.3 – 164.1 feet, maximum tip height 262 feet
• 120 | HT— 120 tons, standard boom 38.3 – 164.1 feet, maximum tip height 262 feet
• 120 | HTLB— 120 tons, standard boom 39.8 – 196.9 feet, maximum tip height 263 feet
• HTT-8675 Series II— 75 tons, standard boom 41 – 127 feet, maximum tip height 230 feet
• HTT-86100— 100 tons, standard boom 38 – 140 feet, maximum tip height 237 feet
• HTT-86110— 110 tons, standard boom 38.3 – 164.1 feet, maximum tip height 262 feet
• 120 | TT— 120 tons, standard boom 38.3 – 164.1 feet, maximum tip height 262 feet
• 120 | TTLB— 120 tons, standard boom 39.8 – 196.9 feet, maximum tip height 263 feet
Tadano
• GT-800XL-2— 80 tons, main boom 39.5 – 154.3 feet, maximum boom length 154.3 feet
• GT-1200XL-2— 120 tons, main boom
Tandem Lift
Truck Cranes
length 41 – 167.3 feet, maximum boom length 167.3 feet
“ As contractors look to improve productivity and maximize equipment utilization, higher-capacity truck cranes are becoming increasingly attractive solutions,” Grace said.“ Industry trends such as infrastructure modernization, grid expansion, renewable energy development, and labor shortages are also influencing purchasing decisions, with customers prioritizing truck cranes that help them complete work more efficiently while maintaining flexibility across a wide range of applications.”
Using Link-Belt 120-ton 120HT truck crane and 275-ton ATC-3275 all-terrain models, American Industrial Contractors of Lexington, Kentucky assembled a new ASTEC asphalt plant at Hinkle Contracting’ s Natural Bridge Stone Co. To upgrade the hot mix asphalt plant serving central and eastern Kentucky, two cranes were used in tandem to lift several large components, including silos and tanks.
Below: All current Grove TMS truck crane models are available with personnel platforms that enable both lifting and crew access with a single machine.
